TMT-750 Mobile CCTV Trailer

Maximum permissible weight is 1,650 lbs. Own weight is 385 lbs, which leaves 1,280 lbs of load capacity on a loading space of 24 by 31 in. That is sized for the MSB-Compact at 420 lbs, with room left over for the batteries, recorder and router fitted inside the cabinet.

No. At 1,650 lbs maximum permissible weight the trailer stays within the towing limits of a standard driver’s license behind a normal van, so the engineer who installs the platform can also tow it. Towing rules differ per country, so check the combination against your own vehicle.

The TMT-750 has no tilt mechanism, which is what keeps it at 385 lbs and low to the ground. A forklift lifts the MSB-Compact onto the bed through the slots in its own base, then four locking pins hold it in place. Where no forklift is available on site, the TMT-1300 tilts to ground level instead.

The bed measures 24 by 31 in, which is the footprint of the MSB-Compact. Larger platforms need a larger trailer: the MSB-Edge at 44 by 44 in and the MSB6 models at 39 by 39 in go on the TMT-1300 or the TMT-2500. Measure your own configuration before ordering.

A heavy nose wheel that tilts up automatically and takes 1,100 lbs static, shock absorbers, a screwed drawbar, a braked overrun brake on a Knott axle rated at 2,975 lbs, a crash bar, a breakaway cable, lighting to legal standard, a 13 pin plug on a stainless steel holder, a spiral cable and a bubble level, all on a solidly welded and hot dip galvanized chassis. Wheels are 185/70R13 off road. The trailer is CE certified and TUV tested.

The TMT-750 is the trailer on its own. Put an MSB-Compact on it and keep it there, and the two together are sold as the MSB-Roadbox, a unit that stays road going instead of being placed and collected each time.
