TMT-1300 CCTV Trailer

1,985 lbs load capacity 1,985 lbs load capacity 49 x 49 in loading space 49 x 49 in loading space Manual hydraulic tilt Manual hydraulic tilt 2,865 lbs permissible weight 2,865 lbs permissible weight
TMT1300 Overview 1 - Transparent

A platform that stands in the yard earns nothing. The TMT-1300 is the single axle CCTV trailer that puts it back on the road behind a normal van: 1,985 lbs of load capacity on a 49 by 49 in bed, a manual hydraulic tilt so no forklift or crane is needed at the far end, and a hot dip galvanised chassis rated at 2,865 lbs permissible weight. One driver, a category B licence, and the platform is on the next site.

Request a Quote

Built to move your platform without a forklift

Loads without a forklift

The bed tilts on a manual hydraulic mechanism, so the platform is winched on and off at ground level. Adjustable forks are set to the width of your cabinet and take the load through its own forklift slots.

1,985 lbs on a 49 by 49 in bed

Own weight is 825 lbs against a permissible weight of 2,865 lbs, which leaves 1,985 lbs for the platform and its equipment. The loading space measures 49 by 49 in.

Handles like a light trailer

The load sits low, which keeps the trailer settled on the motorway and predictable on a rough site track. At 114 by 77 in it still turns into narrow inner city streets and alleys.

Galvanised and secured for the road

The chassis is solidly welded and hot dip galvanised, so winter salt and wet storage do not shorten its life. Tie hooks and lashing rails hold the platform in place and wheel chocks are supplied.

What goes on the TMT-1300

The TMT-1300 is the transport layer of a CCTV trailer. Which platform rides on it, and what is mounted on that platform, stays your choice.

Platforms that fit the bed

Platforms that fit the bed

 Revolutionize security with mobile deploybable CCTV towers

One platform per trip, or two

Download the trailer brochure

Dimensions, load capacities and loading instructions for the TMT-750, TMT-1300 and TMT-2500, in one PDF.

  • Technical specifications and dimensions
  • Load capacity and permissible weight per trailer
  • Loading and unloading step by step
Download CTA Form
Checkboxes

Choose your loading method

Tilt the bed, winch the platform on

The manual hydraulic mechanism lowers the bed to ground level. Set the adjustable forks to the width of the cabinet, pull the platform on over its own forklift slots, lash it down on the hooks and rails and put the chocks in place.

825 lbs Own weight
Manual hydraulic Lifting mechanism
155/70R12 Wheel size
114 x 77 in Overall size
Loading space
49 x 49 in
Load capacity
1,985 lbs
Permissible weight
2,865 lbs
People needed
1 Person

Real-world applications

Where the TMT-1300 puts a CCTV trailer on the road between sites

Three plots, one trailer, one working day

[TE BEVESTIGEN: klantnaam] | Netherlands

Groundworks move on and the platform has to follow. With the tilt bed at ground level, an engineer loads at the first plot, unloads at the second and is back on the road without waiting for a hiab slot.

Load capacity
1,985 lbs
Loading space
49 x 49 in
Crane needed
None
Crew
1 Engineer
Let's talk about your fleet More clients cases

Platforms it carries

MSB-Compact

Smallest base, 420 lbs

MSB-Edge

Solar powered, 880 lbs

MSB6-Basic Plus

20 ft mast, 915 lbs

MSB6-Premium

20 ft mast, heavy duty cabinet
View All Products and Trailers

Receive Personal Advice

Our team of experts is ready to help you find the right solution for your security needs. Fill out the form below and we will get back to you as soon as possible.

Gawain Guedry
Gawain Guedry
Director, North American Sales and Operations

Get in Touch

Have questions about our Mobile Tower Platforms? Our sales team is ready to help you find the perfect solution for your security needs.

Contact our Sales Manager

Ga****@************st.com
+1 702 885 2069

Common questions about the TMT-1300

Load capacity, licences and loading method. What installers, integrators and rental fleets ask before ordering a trailer.

Maximum permissible weight is 2,865 lbs. Own weight is 825 lbs, which leaves 1,985 lbs of load capacity on a loading space of 49 by 49 in. That covers a single Mobile Tower Platform with the batteries, fuel cells and electronics already fitted inside the cabinet.

No. At 2,865 lbs permissible weight the trailer stays inside a category B licence for the usual van and trailer combination, so the engineer who installs the platform can also tow it.

The bed tilts on a manual hydraulic mechanism down to ground level. Set the adjustable forks to the width of your cabinet, pull the platform on over its own forklift slots, lash it to the tie hooks and rails and place the wheel chocks. Where a forklift is already on site, the platform can go straight onto the bed instead.

Any single platform inside 49 by 49 in and under 1,985 lbs. In practice that is the MSB-Compact at 24 by 31 in and 420 lbs, the MSB-Edge at 44 by 44 in and 880 lbs, and the MSB6-Basic Plus and MSB6-Premium at 39 by 39 in and 915 lbs. Loaded up, any of them becomes a road going CCTV trailer. Check your own configuration before ordering.

A heavy support wheel, shock absorbers, wheel chocks, adjustable forks, tie hooks and lashing rails, all on a solidly welded and hot dip galvanised chassis. Wheel size is 155/70R12 and the trailer measures 114 by 77 in overall.

The TMT-2500 takes two, with 3,970 lbs of load capacity on a 98 by 49 in bed and an electric hydraulic tilt. For the MSB-Compact on its own, the TMT-750 minitrailer carries 1,280 lbs. Tell us how your fleet moves and we will point you at the right one.
